Stierli-Bieger 700 Horizontal RAM Bending Machine

Description

Need a ram bender that is highly productive and versatile, yet compact? The Stierli-Bieger 700 Horizontal Ram Bender aims to meet all your needs–from bending to straightening. Featuring a spacious working platform and a strong tool holder that spans ? mm, with a depth of up to 100mm, the 700 allows for shaping tools up to 130mm. We’re proud of the no-maintenance oil-lubricated guided cylinder and hydro-mechanic stroke restriction. Solid steel construction ensures this bender can stand up to the rigors of all your applications. The machine delivers a working pressure of 220 kN to the full stroke length of 350 mm with continuous maximum working speed. The inching and automatic programme and dressing function can be activated by a remote hand control and cable or a food pedal. Stroke limitation operates electro-hydraulically using the unique Stierli switch-off system with Vernier scale and 0 mark. Operate it with the foot switch or special manual control cable, with two modes and a straightening function.

Horizontal Bender Technical Data

test
Working Power
Tool height
Bending output flat
Bending gas pipes
Adjustable stroke
Motor power
Ram speed
Normal voltage
Working height
Dimensions
Weight
Colours
700 kN / 70 to
300 mm
300 / 30 mm
3/8″ – 3″
0 – 350 mm
7.5 kW
0 – 0.6 m/min
400 V / 50 Hz
900 mm
1960 / 1010 mm
2200 kg
NC 3050 blue-green, NC 4050 wine-red
77 U.S. tons
12″ inch
12 x 1 ¼” inch
3/8″ – 3″
0 – 14″ inch
10 HP
0 – 23.6″ inch/min
200 V/220 V / 60 Hz
35″ inch
77″ x 40″ inch
4850 lbs
NCS 3050 blue-green, NCS 4050 wine-red
